556 RESULTS FOUND FOR: used Evaporators

1 2 3 4 5 6 Next
  • AIRCO TEMESCAL BJD-1800

    AIRCO TEMESCAL: BJD-1800

    E-Beam evaporator CTI Cryo pump and compressor, 8" Standard chamber size: 55" x 36" XTAL Controller: IC 6000 4-Pocket gun TEMESCAL 7cc CV-8 Power supply Quartz halogen heaters with heat controller Over: 150ºC IC-600 Film thickness monitor TEMESCAL Viewvac port XYS-8 Sweep control TEMESCAL Auto regeneration on cryo Shutter control Subtraction speed control Power: 208 V.
  • AIRCO TEMESCAL FC 1800

    AIRCO TEMESCAL: FC 1800

    Load-locked e-beam evaporator Substrate heaters Cryo pumped high vacuum system with roughing pump 4-Pocket gun with TEMESCAL Simba power supply INFICON IC4 deposition monitor Bell jar: 19.5" ID 17" Single substrate dome with rotation control Auto valve sequencer.
  • AIRCO TEMESCAL FC 1800

    AIRCO TEMESCAL: FC 1800

    Evaporator INFICON SCQ-310 for dep rate control.
  • AIRCO TEMESCAL: PVD 1800

    Evaporator system Included: (3) 3” Guns Load lock Planetary system with rotation Small frame Power: AE DC Power supplies.
  • AIRCO TEMESCAL: VES 2550

    E-Beam evaporator CV-14 Power supply.
  • AST / ADVANCED SYSTEM TECHNOLOGY Peva-600E
  • BALZERS BA 710

    BALZERS: BA 710

    E-Beam evaporator With LEYBOLD Vertical cylinder BALZERS Primary pump (2) Crucibles.
  • BALZERS BAK 500

    BALZERS: BAK 500

    Vacuum Chambers.
  • BALZERS: BAK 640

    Evaporator Chamber: Stainless steel chamber in eggshell white powder coated With trace water cooling 6 Channels water battery With individual circuit compressed air blowout to all channels Pumping: Pfeiffer pump station: DUO65 Rotary pump With WKP250 roots pump DIF400 Diffusion pump BFA400MF Multi coolant baffle Valve set: PVA400P2 High vacuum valve: Electro-pneumatic EVA063PA Angle valve for bypass pumping EVA025P Angle valve for vent gas Pfeiffer gas inlet valve VDE016 for O2 partial pressure bleed Control system: BPU420G PRO420 Process controller VAC420 Vacuum control Electron beam gun system: EHV110A High voltage power supply (4) Pocket ESQ110 electron beam gun Thermal evaporation source: High current lead ins Glow discharge: BALZERS HGG700 glow discharge system automatic from the process Heating: 6kW Calotte rear surface calrod heater Eurotherm in TKU400 with thermo-couple Substrate holding: BALZERS precision optics calotte system (6) Blank stainless steel sectors Rotary drive system: BALZERS BD104 drive mechanism with water cooling Zurrer DC motor with taco-generator Crystal head: BALZERS QSK610A Six way crystal head monitor Control distributor: ST700 Electrical distributor cabinet (3) 400VAC / 50Hz Power at @65A supply Water chiller: Coolmation TAE cold water chiller / (6) Bar Spare parts: Components and consumables Full Toolbox (10) Crystals (10) Filaments (10) Thermal boats (25) Bulbs (50) Assorted fuses CE Marked.
  • BALZERS EXT70

    BALZERS: EXT70

    Vacuum pump Pumping Speed: 52 lit/sec (Nitrogen) Ultimate Vacuum: 5x10-9 m/bar Inlet Flange: KF40 Outlet Flange: KF16 Minimum Backing Pump Capacity: 0.9 CMH Recommended Backing Pump: E2M0.7 Compatible Controllers: EXC 100E, EXC 120, TIC Series Cooling: Water.
  • BALZERS: USI 2000

    Cleaning line.
  • BOC EDWARDS Auto 306

    BOC EDWARDS: Auto 306

    Vacuum Evaporators Bell jar and shield 12" diameter Fitted with Edwards 8 roughing pump and a diff pump Penning gauge 8 Pirani 10 Partridge 900va transformer 14 lead throughs Filament holder is the only fitting with the unit Number of leadthroughs on the baseplate Can be configured to meet specifications Currently pumped down and hold vacuum (1) Unit has a bell jar, (1) unit has a quartz cylinder No fittings in the chambers.
  • BOC EDWARDS: Auto 306

    Compact Thermal Deposition Evaporator Laboratory sized self-contained thermal evaporator 12" dia. quartz tube chamber with stainless base plate and lid Simple push button automatic vacuum controller Single resistive thermal source Built-in gauges and power supplies Diffusion and roughing pump built-in 210V, 1 Ph, 60 Hz, CE.
  • BUCHI B-414

    BUCHI: B-414

    Scrubber Includes Cooler and glassware 220V, 50/60Hz CE marked.
  • BUCHI R 114

    BUCHI: R 114

    Rotary Evaporator Analog Variable 5-240 rpm speed controls Digital waterbath Temperature range: 20-110°C Plastic coated glass condenser VacuuBrand Vacuum pump Haake K20 chilling circulator Glassware included 110 VAC, 50/60 Hz.
  • CHA 50C RH PC / PLC

    CHA: 50C RH PC / PLC

    Vacuum evaporator Water 9.50 GPM Air 90-100 PSIG N2 Chamber vent: 10-40 PSIG N2 Cryo purge: 60-80 PSIG Power specifications: Voltage: 208 VAC 3 Phase Frequency: 60 Hz Amperage: 175 Amps System IC 10 KVA (5) Wires.
  • CHA 600

    CHA: 600

    Thermal evaporator Includes: CTI cryopump, nonfunctional CTI compressor.
  • CHA SE 1000 RAP

    CHA: SE 1000 RAP

    Multisource e-beam / thermal evaporator For optical films and oxygen reactive evaporations INFICON IC-4 Plus rate and deposition controller Six pocket electron beam source SR-10 E-beam power supply (2) Outrigger style filament resistance sources 6 kW SCR controlled power supply Automatic valve sequence controller Water cooled bell jar: 25" diameter x 30" tall Pressure control system for oxygen reactive evaporations VHS-10 high speed diffusion pump with roughing pump Quartz substrate heaters Slide type fixturing for lift off process Does not use substrate rotation type fixturing Includes parts for optical monitor.
  • CHA: SE 600 RAP

    E-beam Evaporator 18" x 30" high S/S bell jar Inficon IC-6000 thickness monitor Autotech II Automatic/manual valving Ion/dual TC Gauge TEMESCAL CV-14 power supply (14kW) Diffusion pump Four pocket gun 2 Stage direct drive roughing pump Upgrade to rebuilt CTI-8 cryopump head with compressor available Thickness monitor available.
