Reflow Ovens

Tunnel reflow oven.

Reflow oven (7) Heating zones, top and bottom (2) Cooling zones PCB Flow: left to right 20" mesh belt 440 V, 3 phase, 60 Hz, 82 kVA Computer controlled Includes: monitor, keyboard, accessories 1998 vintage.

Reflow oven 2012 vintage.

Reflow ovens 3 Phase, 240 VAC Currently installed.

Reflow oven.

Reflow soldering machine (16) Heating zones: 2760 mm length (2) Cooling zones: forced cooling Heating System: PID Infrared Ray and hot fan Mould Life: 300,000-1,000,000 shots Lead free Temperature range: Ambient to 300°C ± 1°C accuracy PCB Size: 30-350 Mm Reflow Oven: 4030 L/ 700 W/1400 H Mm Convey Speed: 0-2000 mm/ Min Production Capacity: 24 sets/Year Computer controlled PLC 380 VAC, 50 Hz

IR Reflow oven.

Reflow oven 2002 vintage.

Reflow oven.

SMT Reflow soldering oven 2015 vintage.

Reflow soldering machine Maximum temperature rating: 350 °C Nominal operating temperature: 80 - 325°C Number of controlled heated zones: (7) Top / Bottom Heater: BTU Porcupine ii Heater zone 5kw: Zone 1,2,6,7 Heater zone 2.7kw: Zone 3,4,5 Total heated length: 2489 mm Blower accuracy: (5) Degree celcius Total cooling length: 711 mm Oven atmosphere: Air / N2 Gas distribution system: Point 1: Entrance curtain top/bottom Point 2: Zone 1 top/bottom Point 3: Zone 4 and 5 top/bottom Point 4: Zone 6 and 7 top/bottom Point 5: Cooling zone Point 6: Exit curtain top/bottom N2 Feeding zone: Entrance,1,4&5,6&7, cooling, exit O2 Ppm measurement (zone): 1,7 2006 vintage.

Reflow oven (5) Zones Process width: 400 mm Soldering or curing Lead-free processing Full convection heating for even temperature distribution Solder pastes with or without lead Efficient heat transfer Chain conveyor Closed loop controlled conveyor drive system Integrated microprocessor control with LCD Built-in overheat security switches Currently in production.

Reflow oven L-R-Rear Chain type 2001 vintage.

Reflow ovens (9) Zones with chain Mesh: No Center-support Type: Air Right to left Left to right Front rail fixed 2010 vintage.

Reflow oven (8) Zones With rail Upgraded in 2005 With computer Operating system: Windows 2000 Controllers Working flow: Left to right Currently installed 1994 vintage.

Reflow oven Edge and mesh Flow: Left to right 480 V 2004 vintage.

Reflow oven Edge and mesh N2 and oxygen sensor (2) Cool zones 2006 vintage.

Reflow oven Specifications: (7) Zones Atmosphere: Air Conveyor speed: 10-60 in/min 25-152 cm/min Conveyor width: 2-18 in 51-457 mm Heated length: 98 in 2489 mm (7) Heated zones: Top / Bottom Cooling length: 24 in 610 mm (1) Cooling zone (Top/Bottom): Top Voltage range: 208-480 VA Features: Lead free process 350ºC Maximum temperature Forced impingement convection Adjustable heating and cooling rates Side to side gas recirculation Low nitrogen and power consumption Flexible platform configuration WINCON control software Electronic over-temperature safety system Options: 24 in Processing capability Flux management Smart product tracking (SMEMA) Automatic gas sampling 400°C Maximum temperature Closed loop convection control High power heaters Dynamic gas idle Belt and rail conveyors Integrated water supply Retractable center support UL 508A and CE Compliant Fine mesh conveyor belts Low nitrogen consumption package Automatic width adjust Automated water handling 2008 vintage.

Reflow oven.

Reflow oven (7) Zones High-mass Nitrogen capable 1997 vintage.
