Machine Tools

Multi-Spindle Lathe Number of spindles: 6 Capacity round bar: 42 mm Max. turning length: 125 mm Number of cross slides: 6 Spindle speeds: From 140 rpm to 2240 rpm Voltage 50 Hz 3x: 380 Volt Power: 22 kW Accessories: Pick-up device Back drilling attachment.

Automatic Lathe Diameter of work admitted: 4 mm Max turning length: With flat cames: 28 mm Spindle hole: 6 mm Max treading diameter: 4 M (Metric) Number of tool cutters: 5 Number of spindle speeds: 14 m/min From 2000 rpm to 12000 rpm Voltage 50 Hz 3x: 380 Volt Total power required: 1.5 HP Accessories: Slotting attachment: 20 CA Controlled spindle stop device N Electric control-box 2-spindle drilling attachment Controlled clutching device Rocker arm with 1/1000 mm.

Automatic Lathe Diameter of work admitted: 7 mm Max turning length: With flat cames: 60 mm Spindle hole: 8 mm Max treading diameter: 6 M (Metric) Number of tool cutters: 5 Number of spindle speeds: 20 m/min From 1400 rpm to 10000 rpm Voltage 50 Hz 3x: 380 Volt Total power required: 3.0 HP Accessories: Electric control-box 2-Spindle back-drilling att.: 32 AA On pick-up: 12 UB+perçeur transv. 12 UB.

Automatic Lathe Diameter of work admitted: 10 mm Max turning length: With flat cames: 70 mm With bell cames: 100 mm Spindle hole: 12 mm Max treading diameter: 8 M (Metric) Number of tool cutters: 5 Number of spindle speeds: 20 m/min From 1050 rpm to 8000 rpm Voltage 50 Hz 3x: 380 Volt Total power required: 3.0 HP Accessories: Electric control-box Speed accelerator.

Automatic Lathe Diameter of work admitted: 4 mm Max turning length: With flat cames: 50 mm Spindle hole: 6 mm Max treading diameter: 3 M (Metric) Number of tool cutters: 5 Number of spindle speeds: 20 m/min From 1700 rpm to 12000 rpm Voltage 50 Hz 3x: 380 Volt Total power required: 1.5 HP.

Automatic Lathe Diameter of work admitted: 12.5 mm Max turning length: With flat cames: 70 mm With bell cames: 100 mm Spindle hole: 12.5 mm Max treading diameter: 8 M (Metric) Number of tool cutters: 5 Number of spindle speeds: 20 m/min From 1050 rpm to 8000 rpm Voltage 50 Hz 3x: 380 Volt Total power required: 4.0 HP Accessories: Combined 3-spindle attachment: 13Y Back drilling attachment: 12AD Slotting attachment Pick-up attachment 34 DA Controlled clutching device.

Automatic Lathe Diameter of work admitted: 12.5 mm Max turning length: With flat cames: 70 mm With bell cames: 100 mm Spindle hole: 12.5 mm Max treading diameter: 8 M (Metric) Number of tool cutters: 5 Number of spindle speeds: 20 m/min From 1050 rpm to 8000 rpm Voltage 50 Hz 3x: 380 Volt Total power required: 4.0 HP Accessories: Combined 3-spindle attachment: 13Y Pick-up attachment 34 DA Controlled clutching device.

Automatic Lathe Diameter of work admitted: 12.5 mm Max turning length: With flat cames: 70 mm With bell cames: 100 mm Spindle hole: 12.5 mm Max treading diameter: 8 M (Metric) Number of tool cutters: 5 Number of spindle speeds: 20 m/min From 1050 rpm to 8000 rpm Voltage 50 Hz 3x: 380 Volt Total power required: 4.0 HP Accessories: Combined 3-spindle attachment: 13Y Electric control-box Controlled clutching device.

Automatic Lathe Diameter of work admitted: 4 mm Max turning length: With flat cames: 28 mm Spindle hold: 6 mm Max treading diameter: 4 M (Metric) Number of tool cutters: 5 Number of spindle speeds: 14 m/min From 2000 rpm to 12000 rpm Voltage 50 Hz 3x: 380 Volt Total power required: 1.5 HP.

Cutting machine Pile lift Touch screen Programmable Spare knives 1996 vintage.

Horizontal lathe SIEMENS 840C controller 1999 vintage.

Hypoid cutter sharpener Diameter of spiral cutter: 3.5" to 21" Revacycle cutters, infeed attachment: 16" to 25" Coniflex cutters: 9" to 15" Wheel size: 12" x .75" x 4" bore Dresser diamond rotation: 9.2° after each dressing cycle Feeds and speeds: Times per blade: 5 seconds Feed (roughing): 0.007" Feed (finishing): 0.002" Wired for: 3ø, 60 Hz, 230 / 460V Wheel drive motor: 2 HP at 1800 RPM Feed drive motor: 1 HP at 1800 RPM Hydraulic pump motor: 1 HP at 1200 RPM Coolant pump motor: 0.25 HP at 3600 RPM Includes: (2) index plates Wheel arbor Coolant Cutter truing device 1968 vintage.

Gantry loader Maximum Turning Diameter: 4.72" Maximum Turning Length: 3.15" Travels: X-Axis: 5.12" Z-Axis: 5.71" Rapid Traverse Rate: X- & Z-Axes: 945" / Min. Spindle Speeds: 50 – 6000 RPM Spindle Bore: 2.09" Bar Capacity: 1.63" Motors (2) 15 / 10 / 7.5 HP 3/60 Equipped with: Okuma OSP-7000L CNC with 4-Axis Control Okuma OGL Gantry Loader: (1) Carrier, Turnover Station (1) 10-Station Stacker Table (2) Gripper Jaws and Work Pusher for Loading by Hand (2) 6" Kitagawa Hydraulic Chucks, Model B206 (2) 8-Postion Turrets Spindle Orientation Standard Okuma Tool Holder Package High-Lift Rear-Discharge Chip Conveyor Multi-Tap Transformer All Standard Manuals and Schematics 1999 vintage.

Medium duty lathe 20" x 120"~144" Centers 14' of Bed Length Spindle Speeds (18) Optional Range of Spindle Speeds: Low = 17 to 1000 RPM Medium = 25 to 1500 RPM High = 34 to 2000 RPM Complete with: Small Face Plate Compound Rest Single Screw Round Tool Holder English Leadscrew Thread Dial (With English Lead Screw ONLY) Mechanical Apron Control Micrometer Ball Threading Stop Standard #1 Key Drive taper spindle nose Stainless Steel Micrometer dials Chromium plated handwheels and handles 2 Hardened Morse taper #4 centers Adjustable automatic longitudinal feed stop in both directions, and renewable Hardened Tool Steel Outside bedways 18 Speed, Automatic oiler, 100% anti-friction free geared head. Includes: Collet chuck, wheel operated, nose type, for standard taper, spindle nose. Collets for the above chucks, round, 1/16" to 1 3/8", by 1/16" Taper attachment, plain bearing type, with hardened steel guideways. (Max taper 5" per foot, max. length @ one setting 18" Integral chip and coolant pan with reservoir Motor driven coolant pump Large faceplate of 21" diameter Follow rest, plain jaws, iron body, capacity 1/2"~4" Steady rest, plain jaws, iron body, capacity 1/2"~6" 18" diameter steel body independant type chuck, four solid reversible jaws 15" diameter steel body universal type chuck, three jaws, internal and external Electrical Equipment 10 or 15HP, 1800RPM 25" SOW (2) Steady Rest 8 1/4" Taper Attachment Threading Rapid Traverse Spindle Speeds 12~800 RPM 18" 4 Jaw chuck (2 of them) 15" 3 Jaw Chuck 12 1/2" Facing Chuck 2 1/4" Spindle Bore Tooling included Factory manuals 1942 vintage.

Manual press, 1999 vintage.

Low cap universal tester Capacity: 10,000 lbs Separate control console Set of jaws Voltage: 120V.

Mechanical power squaring shear, 1/4" x 161" Cutting capacity - mild steel: 1/4" x 161.42" Table size (T-Slotted): 182" x 24" Throat depth: 2.56" Number of holddowns: 16 Blade length 174.4" Rake taper: 1° 28 ft. Speed: 52 SPM Motor: 15 HP, 3 ph, 60 cyc, 230/460V Flush Floor Mount 10' Squaring Arm (2) Work Supports 24" x 182" T-Slotted Table Inch, Single & Continuous Programmable Width And Number of Cuts Light Beam (40w X 5) Blade Clearance Adjustment With Dial Indicator (4) Edged Blade 40" Front Operated Powered Back Gauge Air Actuated Mechanical Clutch With Foot Switch Operation Lubrication 1993 vintage.

Horizontal machining center FMS cell 8,000 RPM 320 Tool Hive Cat 40 45 Pallet Fanuc 6M control 1 Degree B.

Hybormill horizontal boring mill 5" Spindle diameter Pendant control 50 Taper with power draw bar 43 Selections 7.5-975 spindle rpm 48" Verticle travel 82" Cross travel 64" Long travel Overall 12'2" W x 20'8" x 10'4" H 48" x 98" Table Rapid transverse Outriggers for saddle Some tooling 1967 vintage.

X-ray driller, single head, 2004 vintage.
