Used MICRO VU M302 #293769544 for sale

MICRO VU M302 optical comparator is a sophisticated measurement equipment specifically designed for the production of high-precision components. Utilizing a highly reliable, two-axis optical stage, light source, and 3-step lens system, it provides excellent precision recordings with a resolution of 0.00001" (0.002 mm). MICRO VU M 302 can accommodate a variety of measurements and inspections, from short, straight line designs, to complex contour shapes. The heart of the optical comparator unit is its light source. This uses a low-voltage light source and adjustable optics to project a bright, uniform image, which illuminates the cams, shims, grooves, and textures of your object in detail. The light source employs a proprietary digital light source that delivers a 50-watt lamp at 6,000 lux intensity, with 20X LED brightness. Coupled with a uniquely designed high-speed shutter, this minimized lens aberrations produced by heat from the light source. The piece being measured or inspected is mounted on a two-axis optical stage, which allows for precise and accurate movement of the object for a variety of measurements. The scanning stage is an advanced digital drive machine, with a maximum feed rate of 39.7 inch/min (1 meter/min). A laser reference tool can be used to accurately calibrate the stage position for every measurement, ensuring that the proper point is interpreted for every sample. The optical comparator uses a 3-step process to measure the dimensions of the object. First, a clear, bright image of the object is projected onto the screen, which is overlayed with a highly detailed grid, allowing you to precisely line up and read the measurements. Adjustable lens and lens group controls allow for precise magnification and resolution selections. Once the image is complete, a unique software asset interprets the image, allowing for precise measurement readings. M302 also utilizes a video/CAD interface, which includes nodes that can be set to trigger a variety of measurements, eliminating the need for manual input. Additionally, a host of other features allow for even greater accuracy, such as the Image Processing Model, which reduces optical aberrations and displays the image more clearly and accurately. M 302 is the ideal solution for precise measurement requirements, with its advanced features, highly reliable optical stage, and specialized software. Great for aerospace work, military specifications, and medical devices, MICRO VU M302 optical comparator is one of the most advanced systems in its class.
