Used ELECTROGLAS 2001 #9282032 for sale

ELECTROGLAS 2001 is a wafer prober manufactured by ELECTROGLAS. It is an automated, vision-guided, placement equipment that enables precision probing of semiconductor integrated circuits (ICs). The system features a wafer loader, a wafer prober, an automated X-Y coordinate unit, and a vision subsystem. The wafer loader has two robotic arms for loading and unloading wafer cassettes from the prober. The wafer prober is capable of handling wafer sizes of up to eight inches in diameter and can measure up to 200 wafer surfaces with each cycle. It has a high-precision X-Y stage with a range of 800 x 800 microns and can operate at speeds up to 30,000 microns/second. The automated X-Y coordinate machine is used to align the wafers for probing and can be programmed to probe wafers of any size and shape on the X-Y plane at any position. The vision subsystem utilizes an image-processing chip to detect, scan, and measure the wafer surface for feedback during wafer operations. 2001 has the ability to program custom recipes and provides a number of features designed to speed up test time. It features a barcode reader which is capable of identifying the wafer type, while its automated sorting feature can quickly identify which wafers have already been tested and which have yet to be tested. It also has the ability to control a range of probe cards, up to three probe cards at the same time, allowing for multiple and versatile probing configurations. In addition, it has a number of safety measures designed to improve accuracy, such as a multi-point contact detection tool which can detect external objects or activities on the prober and quickly shut down the asset. All of these features put together make ELECTROGLAS 2001 an efficient and reliable tool for IC probing and inspection.
