Used MRC 903 #293793591 for sale

MRC 903 is a pulsed power, solid state sputtering equipment designed for use in research and development of vacuum deposition processes. 903's state-of-the-art architecture features a pulsed substrate planar magnetron configuration and is capable of direct current (DC) and radio frequency (RF) sputtering. It has a power range of up to 800 W and a range of pulse widths from 1-400µs. The platform is designed for maximum flexibility and control of sputtering processes. MRC 903 sputtering system features a single or dual planar magnetron configuration with a planar 5" X 5" treatment area and source dimensions of 12" X 12". It has an aluminum vacuum chamber with view ports and the chamber can be pumped down to a base vacuum of 4 x 10-7 Torr with a maximum operating pressure of 10 mtorr. Temperature control and monitoring is managed by a Brooten NSTL-20 digital chamber thermocontroller. A control panel with a graphical display provides control of sputtering parameters such as power, pulse width, rate, frequency and substrate temperature. User-friendly macros allow selection of optimum operating parameters with a single button push. The software includes a wide range of predetermined applications profiles for up to 10 different sputtering configurations and multiple different materials. A mass flow controller enhances accuracy by accurately metering the gas flow for reactive sputtering operations. High performance is achieved through detailed control of the optimum pressure rail potential during operation. 903 is ideal for the deposition of a wide range of compounds, from insulators to semi-conductors. It has a wide range of applications in the manufacture of thin film products such as semi-conductors, display screens, solar cells and automotive coatings. As well as having high accuracy, precision and repeatability, MRC 903 offers high throughput with large area deposition and is suitable for production processes. 903 sputtering unit is safe and reliable and can be integrated into existing vacuum setups with ease. It is built to last, with high durability components and low maintenance requirements. The machine runs quietly and offers a small form factor which makes it suitable for tight spaces. MRC 903 is the perfect tool for any cleanroom research lab or industrial facility.
